Sorotec Has 20 Years Manufacturing Experience In Power Supply
Language
Sorotec Has 20 Years Manufacturing Experience In Power Supply
Min. Order: 10 Pieces
Port: Shenzhen, China
Production Capacity: 5000PCS/Month
Payment Terms: L/C, T/T
Nature of Source Flow: Active Inverter
Phase: Single
Output Power: >1000W
Certification: CE, ISO9001
Brand: Sorotec
Type: DC/AC Inverters
At SOROTEC, technology improvement and innovation are our core advantages. Since established, we have been focusing on developing new products, improving product quality, and serving customers. off grid solar inverter for sale SOROTEC have a group of service professionals who are responsible for answering questions raised by customers through the Internet or phone, tracking the logistics status, and helping customers solve any problem. Whether you'd like to get more info on what, why and how we do, try our new product - Bulk off grid solar inverter for sale high safety, or would like to partner up, we'd love to hear from you.SHENZHEN SORO ELECTRONICS CO., LTD. has set up fairly large scale modern production line.
Model NO. | REVO VP/VM |
Power Source Solr Power |
|
Circuit Topologies | Half-Bridge Type |
Nature of Wave String | Sine Wave Inverter |
Nominal Output Voltage | 220/230/240VAC |
Power Factor | =1.0 |
Maximum Conversion Efficiency (DC/AC) | up to 93.5% |
Frequency Range | 50Hz/60Hz (Auto Sensing) |
Maximum Solar Charge Current | 90A |
Maximum AC Charge Current | 60A |
Humidity | 0~90% Rh (No Condensing) |
Operating Temperature | 0 to 50 °c |
AC Voltage Regulation (Batt. Mode) | 230VAC ± 5% |
Transfer Time | 10 Ms (for Personal Computers) ; 20 Ms (for Ho |
Battery Voltage | 24 VDC |
Solar Charger Type | MPPT |
Communication Interface | USB/RS232 |
Trademark | SOROTEC |
Transport Package | Standard Exported Package |
Specification | 50*40*21cm |
Origin | China |
Key Features:
Pure sine wave solar inverter
Output power factor 1
Selectable high power charging current
Wide DC input range
Selectable input voltage range for home appliances and personal computers
Confifigurable AC/Solar input priority via LCD setting
Compatible to AC mains or generator power
Auto restart while AC is recovering
Overload and short circuit protection
Smart battery charger design for optimized battery performance
Cold start function
Optional anti-dusk kit
Wall Mounted Integrated Solar Power Inverter Technical Specication
Built-in MPPT/PWM Solar Controller
| MODEL | REVO VP 1000-12 | REVO VM 1200-12 | REVO VP 2000-24 | REVO VM 2200-24 | REVO VP 3000-24 | REVO VM 3200-24 | REVO VP 5000-48 | REVO VM 5000-48 |
| Rated Power | 1000VA/1000W | 1200VA/1200W | 2000VA/2000W | 2200VA/2200W | 3000VA / 3000W | 3200VA / 3200W | 5000VA / 5000W | |
| INPUT | ||||||||
| Voltage | 230 VAC | |||||||
| Selectable Voltage Range | 170-280 VAC (For Personal Computers) ; 90-280 VAC (For Home Appliances) | |||||||
| Frequency Range | 50 Hz/60 Hz (Auto sensing) | |||||||
| OUTPUT | ||||||||
| AC Voltage Regulation (Batt. Mode) | 230VAC ± 5% | |||||||
| Surge Power | 2000VA | 4000VA | 6000VA | 10000VA | ||||
| Efficiency(Peak) | 90% ~ 93% | |||||||
| Transfer Time | 10 ms (For Personal Computers) ; 20 ms (For Home Appliances) | |||||||
| Waveform | Pure sine wave | |||||||
| BATTERY | ||||||||
| Battery Voltage | 12 VDC | 24 VDC | 48 VDC | |||||
| Floating Charge Voltage | 13.5 VDC | 27 VDC | 54 VDC | |||||
| Overcharge Protection | 16 VDC | 31 VDC | 33 VDC | 63 VDC | ||||
| SOLAR CHARGER & AC CHARGER | ||||||||
| Solar Charger type | PWM | MPPT | PWM | MPPT | PWM | MPPT | PWM | MPPT |
| Maximum PV Array Open Circuit Voltage | 55 VDC | 102 VDC | 80 VDC | 102 VDC | 80 VDC | 102 VDC | 105 VDC | 145 VDC |
| Maximum PV Array Power | 600 W | 700W | 1200 W | 1400 W | 1200 W | 1800 W | 2400 W | 3000 W |
| MPP Range @ Operating Voltage | N/A | 17 ~ 80 VDC | N/A | 30 ~ 80 VDC | N/A | 30~80 VDC | N/A | 60~115 VDC |
| Maxmum Solar Charge Current | 50 A | 50 A | 50 A | 50 A | 50 A | 65 A | 50 A | 65 A |
| Maximum AC Charge Current | 20 A | 20 A | 20 A | 20 A | 25A | 25A | 60 A | 60 A |
| Maximum Charge Current | 50 A | 60 A | 50 A | 60 A | 70 A | 60 A | 110 A | 120 A |
| PHYSICAL | ||||||||
| Dimension, D x W x H (mm) | 88 x 225 x 320 | 103 x 225 x 320 | 88 x 225 x 320 | 103 x 245 x 320 | 100 x 285 x 334 | 118.3 x 285 x 360.4 | 100 x 300 x 440 | 100 x 302 x 440 |
| Net Weight (kgs) | 4.4 | 4.4 | 5 | 5 | 6.3 | 6.5 | 8.5 | 9.7 |
| Communication Interface | USB/RS232 | |||||||
| ENVIRONMENT | ||||||||
| Humidity | 5% to 95% Relative Humidity (Non-condensing) | |||||||
| Operating Temperature | -10°C to 50°C | |||||||
| Storage Temperature | -15°C to 60°C | |||||||
APPLICATION OF OUR PRODUCT
1. Living house and home building.
2. Office building, factory and warehouse.
3. Shopping mall, stadium and so on.
4. Power station, field operation and some huge engineer construction.
5. suitable for various home appliance, Office equipment,Journeys, Camping, Tents, Boat Trip.
To draw in more users and consumers, industry innovators are continually developing its qualities for a larger range of application scenarios. Additionally, it can be customized for clients and has a reasonable design, all of which help grow the customer base and loyalty.
Regarding the attributes and functionality of the off grid solar inverter for sale, it is a kind of product that will always be in vogue and offer consumers limitless benefits. It can be a long-lasting friend for people because it is constructed from high-quality raw materials and has a lengthy lifespan.
In essence, a long-standing off grid solar inverter for sale organization runs on rational and scientific management techniques that were developed by smart and exceptional leaders. The leadership and organizational structures both guarantee that the business will offer competent and high-quality customer service.
Regarding the attributes and functionality of the off grid solar inverter for sale, it is a kind of product that will always be in vogue and offer consumers limitless benefits. It can be a long-lasting friend for people because it is constructed from high-quality raw materials and has a lengthy lifespan.
The application of the QC process is crucial for the quality of the final product, and every organization needs a strong QC department. off grid solar inverter for sale QC department is committed to continual quality improvement and focuses on ISO Standards and quality assurance procedures. In these circumstances, the procedure may go more easily, effectively, and precisely. Our excellent certification ratio is a result of their dedication.
SHENZHEN SORO ELECTRONICS CO., LTD. always considers communicating through phone calls or video chat the most time-saving yet convenient way, so we welcome your call for asking for the detailed factory address. Or we've displayed our e-mail address on the website, you are free to write an E-mail to us about the factory address.
Patents: all patents of our products.
Experience: rich experience in OEM and ODM services
